| Measuring Range |
-40 to 60°C, 0 to 100°C, 50 to 150°C (0 to 50°C is only available for display)
(A sensor in use is automatically identified and the range is switched) |
| Accuracy Rating |
±1.0°C ±1digit (Within a rang -5 to 50°C is ±0.5°C ±1digit) |
| Temperature Sensor |
Built-in/External sensor switching (It switches automatically when external sensor is inserted, measuring range of the built-in sensor is -20 to 55°C) |
| Input Point |
1 point |
| Number of Logging Data |
6,000 data (Approx. 8 months worth of data storage at 60min. interval measurement) |
| Logging Method |
Auto stop mode at specified condition or endless mode set at PC. |
| Communication Function |
It comes as standard.
Connect to the PC through data reader (sold separately). |
| Display |
Reflection type LCD |
| Display Contents |
Current Data |
Month, day, hour, minute and temperature (°C) |
| Recalling Data |
Data being stored per month, day, hour, minute or the following data in the logger
- Integration data (°CH), which is set reference temperature or lower (L) or higher (H)
- Number of higher or lower limit activated alarms and month, day, hour, minute and temperature of activated alarm
- Highest, lowest, and average temperatures
|
| Parameters |
Clock: Year, month, day, hour, and minute (Corresponding to leap years)
Start time: Month, day, hour, and minute
Measurement interval: 1 to 60min. (1-minute resolution) or 10 to 50sec. (10-second resolution)
Reference temperature: Reference temperature for temperature integration calculation |
| Integration Function |
H integration or L integration |
| Alarm |
High limit or low limit alarm |
| Power Supply |
Battery type R03 (AAA), 2pcs
Battery life: Approx. 1 year (Recording at 25°C, 1min. interval)
|
| Working Temperature/Humidity Range |
-20 to 55°C, 10 to 80%RH (No dew condensation) |
| Storage Environment |
-20 to 55°C, 90%RH or lower (No dew condensation) |
| Case Protection Structure |
IP64 (Washable) |
| Case Material/Color |
ABS resin, PANTONE® color (552C equivalent) |
| External Dimensions/Weight |
W54×H110×D20.5mm, Approx. 95g (including b |
