| MEASUREMENT DATA |
|
| SCALES |
Optical rotation [°]
Int. sugar scale [°Z]
Concentration [g/100 ml]
Spec. rotation
User-defined |
| MEASUREMENT RANGE |
±90°
±259 °Z |
| MEASUREMENT ACCURACY |
±0.003°
±0.01 °Z |
±0.002°
±0.01 °Z |
| RESOLUTION |
0.001°
0.01 °Z |
| MEASUREMENT PERIOD ±90° |
Approx. 1 s |
| LIGHT SOURCE |
1 LED with filter |
| WAVELENGTH |
589 nm |
| TEMPERATURE DATA |
|
| TEMPERATURE CONTROL |
With Circulation Thermostat PT31/PT80 and temperature-controlled measurement tube |
| TEMPERATURE CONTROL RANGE |
5–80 °C |
| TEMPERATURE CONTROL ACCURACY |
±0.2 °C |
| TEMPERATURE MEASUREMENT |
With temperature probe PRT-E or PRT-T |
| TEMPERATURE MEASUREMENT RANGE |
0–99.9 °C |
| TEMPERATURE MEASUREMENT RESOLUTION |
0.1 °C |
| TEMPERATURE MEASUREMENT ACCURACY |
±0.2 °C |
