Excellent long-term stability: The resistance elements are made of selected manganin wire, stabilized by both artificial and natural aging after being wound.
Perfect guard system
Stable measurement: The dial switches offer low contact resistance and little change due to aging, giving stable operation. Inner/outer contact type plugs are used for changing the multiplication factor, assuring little change in the resistance due to reinsertion of plugs.
Laboratory-grade accuracy ±0.03 to ±0.05%
Quick readout without error
Built-in standard resistors
Bar resistor measurement
Thông số kỹ thuật
| Dimensions |
497（W）×316（H）×140（D）mm, excluding protrusions
19.57 x 12.44 x 5.51 in. |
| Weight |
Approx. 11.5kg
25.4 lbs |
| Measuring Range |
0.1000mΩ to 111.10Ω in five digits |
| Measuring Arm |
(At Multiplier x1) 100mΩ x 10 + 10mΩ x 10 + 1mΩ x10 + (0.05 to 1.05mΩ) |
| Multiplier |
x 0.001 x 0.01 x 0.1 x 1 x 10 x 100 |
| Accuracy |
At resistances potential
Leads and current leads less then 10mΩ/wire;
±(0.03Ω of reader +1µΩ) at temperature at 10 to 35°C±2.5°C,
±(0.05Ω x multiplier +0.01mΩ) at temperature at 10 to 40°C |
| Insulation Resistance |
More than 100MΩ at 500V DC between the electric circuit and the case |
| Dielectric Strength |
500V AC for one minute between electric circuit and case |
| Case |
Grey metal Case, with plastic feet and carrying handles |
| Current Rating |
30A at x 0.001, 10A at x 0.01, 3A at x 0.1, 0.5A at x 1, 0.15A at x 10, 0.05A at x 100 |
| Optional Accessories |
2012 DC Volt-ammeter
2707 electronic galvanometer (rear cover)
2753 Measuring Cords
2754 clamp device.
2791 Slide resistor |
