| Input Voltage |
24 VDC @ 1A from external power supply (100-240 VAC 50/60 Hz) or from tool power |
| Discharge |
Between 2-2.5 sec @ 1 ft (typ), taken in-line from the center of the fan (±1000V-100V)
|
| Balance |
±3V or better balance (±1V with the optional external feedback system) |
| Cleanroom Class |
Meets ISO 14644-1 Class 4 (Fed Std. 209E Class 10) |
| Dimensions |
Blower: 4.5H x 3.3W x 2.4D in.
(11.5H x 8.3W x 6.1D cm)
Control Box: 1.0H x 5.2W x 2.4D in.
(2.5H x 13.2W x 6.0D cm) |
| Weight |
Blower 1.14 lb (.51 kg); Control Box 0.56 lb (.25 kg) |
