| Measurement Range |
20~300Pa.s (20~50Pa.s 20rpm ・50~300Pa・s 10rpm) |
| Sample Amount |
0.2cc |
| Speed Range (N) |
1~100RPM
FIX: 10rpm |
| Shear Rate (D) |
0.6×Ns-1 |
| Measurement Accuracy |
±5% of the indicated value |
| Speed Accuracy |
±2% |
| Temp. Control Range |
15～40℃ (when the room temp. is 25℃) Built-in thermostat |
| Temperature |
0~50℃ Resolution: 0.1℃ Accuracy: ±0.5℃ |
| Sensor |
SUS |
| Digital Display |
Viscosity ・ Temp. ・ rpm |
| Digital Output |
USB |
| Recorder Output |
Viscosity: 1mV／Pa・s Temp: 10mV／℃ |
| Calibration |
JIS Z8809 Standard Fluid for Viscosity Calibration or
Semi-standard calibration fluid KF96 (option) |
| Power Supply |
AC100V～240V 50／60Hz 100VA |
| Outer Dimension |
315(D) x 335(W) x 376(H) mm |
| Weight |
Approx. 8kg (including sensor part, approx. 1kg)
|
