CO55L |
C100L |
C160L |
C390L |
| Measurement Range |
1000 to 2000 °C / 1832 to 3632 °F |
600 to 3000 °C / 1112 to 5432 °F |
200 to 1400 °C / 392 to 2552 °F |
450 to 1400 °C / 842 to 2552 °F |
| Display |
External backlit LCD display
4-digit LCD in viewfinder |
External backlit LCD display
5-digit LCD in viewfinder |
External backlit LCD display
5-digit LCD in viewfinder |
External backlit LCD display
4-digit LCD in viewfinder |
| Measuring Mode |
Continuous, Peak, Valley and advanced Meltmaster |
Continuous, Peak, Valley and Average |
Continuous, Peak, Valley and Average |
Continuous, Peak, Valley and Average |
| Data Logging |
9999 readings and 9 routes internally; Mobile (4GB standard storage) or PC logger software ( via Bluetooth® or USB connector) |
| Data Logging Modes |
Classic, Burst, Latched, Route |
| Optical System |
9° field of view; eyepiece adjustable -3.75 to +2.5 diopters
|
| Focusing Range |
Fixed focus, nominally at 5 m / 197 in. from pyrometer body datum |
1 m / 39.3 in. to infinity 450 to 620 mm / 17.7 to 24.5 in. and 215 mm / 8.5 in. fixed focus - with optional close-up lens |
1 m / 39.3 in. to infinity 460 to 630 mm / 18.1 to 24.8 in. and 217 mm / 8.5 in. fixed focus - with optional close-up lens |
1 m / 39.3 in. to infinity |
| Minimum Target Size |
Parallel 28 mm / 1.1 in target spot diameter from lens to 5 m / 197 in |
5 mm at 1 m / 0.19 in. at 39.3 in., 1.8 mm / 0.07 in. and 0.4 mm / 0.016 in. - with optional close up lens |
5 mm at 1 m / 0.19 in. at 39.3 in., 2.0 mm / 0.08 in. and 0.5 mm / 0.2 in. - with optional close up lens |
4.8 mm / 0.19 in. at 101.4 cm, / 39.9 in nominal from the pyrometer body datum |
| Spectral Response |
Nominally 0.55 μm |
1 μm with advanced spectral filtering |
1.6 μm with advancedspectral filtering |
Nominally 3.9 μm |
| Emissivity Adjustment |
0.10 to 1.20 in 0.01 step graduations |
| Response Time |
30 ms |
30 ms |
30 ms |
<500 ms (to 98%) |
| Display Update Time |
0.5 s |
| Accuracy |
<0.5% (K) |
≤0.25% (K) |
± 0.25% C + 2 °C |
±0.5% (K) |
| Measurement Resolution |
0.1 °C / 1 °F |
| Measurement Field of View |
Fixed Focus |
180:1 circular |
180:1 circular |
180:1 square |
| Repeatability |
<1 °C / 2 °F |
≤1 °C / 2 °F |
≤1 °C / 2 °F |
≤1 °C / 2 °F |
Operating Temp. Range
|
0 to 50 °C / 32 to 122 °F |
| Power Requirement |
One MN1604 / 6LR61 / PP3 Battery or USB |
| Output |
Bluetooth® / USB Connector |
| Weight |
0.83 kg / 1.8 lb. |
| Sealing |
IP40 |
| Free Data-Logger Software |
Software available at Cyclops Logger (PC & Mobile) |
| Standard Accessories |
Lens cap, protection window/filter, battery, wrist strap, USB cable, heat protection jacket |
| Optional Accessories |
Waterproof carry case, long eye relief eyepiece |
Close-up lenses, waterproof carry case, long eye relief eyepiece, Neutral Density filters: Options 1F or 2F - filters darken the image to provide better image contrast on bright targets, use two for higher temp. applications. |
Close-up lenses, waterproof carry case, long eye relief eyepiece |
Waterproof carry case, long eye relief eyepiece |
