Construction
Stainless steel ionisation head and guard, PTFE ionising head, plastic handle, aluminium nozzle.
Cable
Purpose designed Hi-Flex HT cable is flexible, light and very durable. Standard lengths of 3 m, 5 m, 7 m and 10 m.
Safety
The ionisation system is shockless and meets OSHA and other safety standards, as the nozzle cannot be dead-ended.
Power Unit
Use with Fraser 5.5 kV or 6 kV Power Units - see separate Datasheets.
Air Supply
Maximum air pressure 10 Bar. Typical working pressure is 5 Bar. Air consumption at 5 Bar is 560 lit/min for continuous operation. Air must be clean and dry.
Air Connection
1/4” BSP threaded connection with 8 mm OD push-fit air fitting as standard. Use minimum of 6 mm ID supply pipe. If supply pipe is long use larger ID tubing.
Thrust
At 5 Bar the thrust at a distance of 100 mm is a market leading 5.2 N (airspeed x volume which represents cleaning power).
Environmental
At 5 Bar noise level is 74 dBA, measured at 1000 mm.
Certification
CE.
Options
Air feed to top or bottom of Gun.
