Construction
Extruded PVC with ABS endcaps, epoxy resin. Stay-sharp alloy emitters at 10 mm pitch.
Dimensions
20 x 45 mm (W x H). Available Lengths: minimum 100 mm, then in 100 mm steps to 4000 mm. Active length = overall length -70 mm. A 60 mm option is available for specialist applications.
Cable
2 m HV cable as standard. Longer lengths can be specified at time of order. Max cable length 10 m. Cable terminates in HV connector. Protective nylon conduit on cable. Minimum bend diameter 100 mm.
Safety
100 MOhm resistance for safe operation.
Environmental
Clean, dry and oil-free location. Temperature: 0 - 60 °C, 70 % rH non-condensing max.
Generator
7081: use with Fraser 30 kV Generators. 7080: use with Fraser 7330 and 7324 Generators. State generator model at time of order.
Certification
CE.
Options
Tungsten emitters at 5 mm pitch (7080-T5 and 7081-T5). 90° cable outlet.
