Construction
Anodised aluminium, epoxy resin, ABS and hardened emitters.
Dimensions
1100 - 14.0 x 17.2 mm, 1100-S - 14.0 x 19.9 mm (W x H). Available Lengths: from 60 mm, to 3000 mm. Active ionisation length = overall bar length - 20 mm.
Weight
0.45 kg per metre.
Cable
Hi-Flex 30 kV screened cable with 70 mm bend diameter. Standard length is 2 m - longer lengths can be specified at time of order (subject to maximum load on power unit).
Safety
5 mA maximum current from power unit. High voltage resistance inside bars further limits current below 50 μA.
Power Unit
Use with Fraser 5.5 kV and 6 kV Power Units. See Datasheets.
Environmental
60 °C maximum temperature. 70 % rH non-condensing max. IP66. Fully sealed.
Certification
CE.
Options
Available in 2 versions - 1100 with fixed mounting studs and 1100-S with adjustable mounting studs.
