| Parameters |
ACR, DCV |
| Accuracy |
R：0.5% V：0.01% |
| Range |
R：0.001mΩ~33.000kΩ V：0.00001V~400.000VDC |
| Signal Source |
AC 1kHz，Test current：<150mA |
| Range |
Automatic & Manual, 7 ranges |
| Speed |
30 times/s, 10 times/s, 1 times/s |
| Result Display |
show, ΔABS,Δ%,θ, sorting results |
| Display Max |
R：33,000 V：400,000 |
| Adjustment |
short-circuit reset for all range |
| Comparator |
18 bin sorting, RHI/RNG/RLO output VHI/VNG/VLO output Absolute tolerance ±TOL sorting Percent tolerance TOL sorting Sequence comparison sorting |
| Trigger |
Internal, Manual, External, Remote |
| Interface |
RS-232C , Handler（PLC） |
| Options |
ATL609 Test Fixture |
| Power |
V：195VAC～245VAC Fre：50Hz Power：15VA |
| Dimensions |
264 x107x350 mm |
| Mass |
4KG |
| Accessories |
ATL502 Kelvin test leads、 ATL108 RS232 communication cable，ATL502A test probe |
| Other functions |
Detection of damage test wire, TFT-LCD display, keypad lock and data hold function, internal memoryand u-disk record |
