Thiết bị đo công suất điện năng CAMILLE BAUER U1281 MID, U1389 MID
Installation itself is extremely simple because the meter detects connection errors, which are indicated immediately. Maximum convenience is assured by displaying active power, which provides immediate information regarding momentary circuit load. If more information about the electrical system is required, functionality is simply expanded.
Professional energy meters for 2, 3 and 4 wire systems with 65 A direct connection, or 1 A or 5 A transformer connection
Accuracy class B for industrial and commercial use, as well as for household use with highly demanding requirements
Cost savings thanks to initial calibration at the factory in accordance with MID, conformity assessment procedure modules B and D
Calibration even with adjustable transformation ratios
Configurable, multifunctional variants for acquiring reactive energy and mains quantities
Installation errors display: phase sequence, phase failure, transformers with reversed polarity, overload
Universal pulse output with adjustable pulse rate and pulse duration, as well as selectable voltage range
Flexible communication via integrated LON, M-Bus or L-Bus interface
Full functionality even when the electrical circuit is switched off thanks to failsafe 24 V auxiliary voltage
