- Wavelength sensitivity: This is 300 ~ 400nm, range up to 19.99mW / ㎠ digital ultraviolet intensity meter capable of measuring up to.
- Wavelength sensitivity characteristics: 300 ~ 400nm
- With HOLD function to fix display the measured value.
- MAX (maximum value) / MIN (minimum value) with memory function.
- With auto power-off function. (It turns off automatically if there is no final button operation from the operation 10 minutes.)
Thông số kỹ thuật
| Measurement range |
199.9μW / ㎠, 1.999mw / ㎠, 19.99mw / ㎠
|
| resolution |
0.1μW / ㎠, 0.001mw / ㎠, 0.01mw / ㎠ |
| Measurement accuracy |
± (2% FS + 2dgt) |
| Wavelength sensitivity characteristics |
300 ~ 400nm
|
| sensor |
UV sensor |
| display |
3.5-digit LCD display |
| sampling |
2.5 times / sec. |
| Over display |
"-----"Show |
| Use temperature and humidity |
0 ~ + 50 ℃, 80% RH or less (without condensation) |
| Storage temperature and humidity |
-10 ~ + 50 ℃, 70% RH or less (without condensation) |
| Power supply |
One 9V type battery × |
| Battery life |
About 100 hours (when using alkaline batteries) |
| Dimensions and weight |
[Body] W72 × H180 × D32mm
[Sensor] φ38 × H27mm, code length of about 400mm
[Weight] about 335g
|
| accessories |
UV sensor, carrying case, instruction manual |
| option |
WINDOWS XP-compatible software + communication cable: SWS-001U￫ complete production |
| Proofreading |
Yes |
