| Input channels 1-2/4/8 |
| Resolution |
24 bit |
| Real-time bandwidth |
DC ... 80kHz @ 8 channels |
| Dynamic range |
120dB |
| Noise |
< 1μV(A), < 2μV(Z) @ 0.1Hz ... 40 kHz |
| Sample rates |
200Hz to 204.8kHz |
| Decimation |
up to 200Hz sample rate, selectable per channel |
| Anti-aliasing filter |
yes |
| Max. input voltage |
±10Vpeak @ head room of 1dB |
| Gain |
0dB, 20dB |
| Over-voltage detection |
yes |
| Phase shift |
< 0.1° @ 20Hz ... 20 kHz |
| Offset correction |
yes, automatically at internal calibration |
| Imput coupling |
DC, AC 0.15Hz, HP 1Hz, HP 10Hz, LP 2kHz |
| Microphone voltage supply |
±14V, +20/63/200V switchable (for BNC versions on AUX) |
| ICP supply |
2/4mA switchable |
| Cable error detection |
yes, for ICP sensors |
| TEDS according to IEEE 1451.4 |
yes |
| AUX channels |
| Digital input |
2x TTL |
| Digital output |
2x TTL |
| Sensor supply |
±14V, +20/63/200V switchable |
| Auxiliary channels 1-8 |
| Resolution |
24 bit |
| Real-time bandwidth |
DC ... 200Hz @ 8 channels |
| Input voltage |
-25V ... +25 V |
| Output channels 1-2 |
| Resolution |
24 bit |
| Bandwidth |
DC ... 20/40/80kHz |
| Max. output voltage |
±3.16Vpeak |
| Special channels |
| Trigger |
2x trigger / tacho, trigger level adjustable 0.1Hz ... 6 MHz |
| Synchronisation |
Sample-accurate synchronisation with external clock (e.g. GPS 1Hz) |
| Dimensions and weight |
| Dimensions |
280mm x 220mm x 65mm |
| Weight |
3100 g |
| Battery |
Lithium-ion battery, 4 h measurement capacity |
| External power supply |
100 ... 240VAC or 10 ... 36VDC with adapters |
