| Input channels 4 |
| Plug type |
Lemo NIM-CAMAC (BNC Adapter cable available) |
| Resolution |
24 bit |
| Real-time bandwidth |
DC ... 51.2kHz @ 4 channels |
| Dynamic range |
110dB |
| Noise |
< 1μV(A), < 2μV(Z) @ 0.1Hz ... 20 kHz |
| Sample rates |
200Hz to 51.2 kHz |
| Decimation |
up to 200Hz sample rate, selectable per channel |
| Anti-aliasing filter |
yes |
| Max. input voltage |
±10Vpeak @ head room of 1dB |
| Gain |
0dB, 20dB |
| Over-voltage detection |
yes, automatically with self-calibration |
| Phase shift |
< 0.1° @ 20Hz ... 20 kHz |
| Offset correction |
yes, automatically at internal calibration |
| Imput coupling |
DC, AC 0.15Hz, HP 1Hz, HP 10Hz, LP 2kHz |
| ICP supply |
2 mA |
| Cable error detection |
yes, for ICP sensors |
| TEDS according to IEEE 1451.4 |
yes |
| Output channel |
| Resolution |
24 bit |
| Bandwidth |
DC ... 20 kHz |
| Max. output voltage |
±3.16Vpeak |
| Plug type |
Lemo NIM-CAMAC (BNC Adapter cable available) |
| Special channels |
| Trigger |
2x trigger / tacho, trigger level adjustable 0.1Hz ... 6 MHz |
| Plug type |
Lemo NIM-CAMAC (BNC Adapter cable available) |
| Synchronisation |
no |
| Dimensions and weight |
| Dimensions |
226 mm x 156 mm x 28 mm |
| Weight |
950 g |
| Battery |
Lithium-ion battery, 12 h measurement capacity |
| External power supply |
100 ... 240VAC or 5 VDC with adapters |
