| Power Supply Voltage |
AC100V±10%, 50/60Hz
|
| Operating Temperature |
0~50℃, less than 85%RH (w/o condensation) |
| Storage Temperature |
- 20~60℃, less than 85%RH (w/o condensation) |
| Withstanding Voltage |
AC1000V, 1 minute between power input and case
AC1000V, 1 minute between signal output and case |
| Insulation Resistance |
more than 100MΩ by DC500V insulation tester
between power input and case
more than 100MΩ by DC500V insulation tester
between signal output and case |
| Dimension & Weight |
85.5(H)x110(W)x 5(D)mm, Approx. 300gs. |
| OTHER SPECIFICATION |
Test Function: By pushing test switch, warning lamp lights and output signal becomes ON.
Reset Fuction: By pushing reset switch, warning lamp goes out and can reset it.
In case of operating when reset, warning lamp lights again.
|
