| Technical Parameters |
| Description |
Specifications |
| Type |
Insertion:Flanged |
| Measuring |
Various gases(Except the acetylene) |
| Pipe Size |
DN10~DN4000mm
|
| Velocity |
0,1~100Nm/s |
| Accuracy |
±1~2.5% |
| Working Temperature |
Sensor:-40°C~+220°C
Transmitter:-20°C~+45°C
|
| Working Pressure |
Insertion Sensor:medium pressures≤1.6MPa
Flanged Sensor:medium pressures≤1.6MPa
Special pressure please contact us
|
| Power Supply |
Compact type: 24VDC or 220VAC,Power consumption≤18W
Remote type: 220VAC,Power consumption≤19W
|
| Response Time |
1s |
| Output |
1-2 line 4-20mA (optoelectronic isoltion,maximum load 500Ω),Pulse,RS485(optoelectronic isolation) |
| Alarm Output |
1-2 line Relay,Normally Open state,10A/220V/AC or 5A/30V/DC |
| Sensor Type |
Standard Insertion ,Hot-tapped Insertion and Flanged |
| Construction |
Compact and Remote |
| Pipe Material |
Carbon steel,stainless steel,plastic,etc |
| Display |
4 lines LCD
Mass flow,Volume flow in standard condition,Flow totallzer,Date and Time,Working time,and Velocity,etc
|
| Protection Class |
IP65 |
| Sensor Housing Material |
Stainless steel(316) |
