| General Specifications |
| Voltage |
220V |
| Frequency |
47Hz to 440Hz.Automatically sensed at power-on |
| Power Consumption |
40VA peak (30Watt average) |
| Temperature |
Operating : 0°C to 50°C |
| Full accuracy :18°C to 28°C |
| Storage : -20°C to 70°C |
| Warm-up |
90 mins for full uncertainty specifications |
| Relative Humidity (non-condensing) |
Operating : |
0°C to 28°C < 90% |
| |
28°C to 40°C < 75% |
| |
40°C to 50°C < 50% |
| Storage : |
-20°C to 70°C < 95% |
| Altitude |
Operating : 2000 m |
| Storage : 12000 m |
| Vibration and Shock |
Complies witd MIL-28800F Class 3 |
| Input Protection |
50V all functions, ranges and terminals |
| Communication |
USB-A , USB-B , RJ45 , WiFi , Bluetootd |
| Memory |
10G - All data stored witd time stamps |
| Localization |
English , Chinese |
| Display |
10.1 in (256 mm) TFT color display |
| Size (H x W x D) |
9.8 in (250 mm) x 16.5 in (420 mm) x 7.9 in (200 mm) |
| Weight |
18.5 lb ( 8.39 kg) |
| Other Conformities |
CE |
