| Sensor Type |
NTC thermistor |
| Recordable temperature range |
-30 ~ + 70 ℃ |
| resolution |
0.1 ℃ |
| Temperature accuracy |
± 0.5 ℃ |
| Log type |
One-time use |
| Poly bag size with zipper |
About L105 × W65 × T4mm |
| Product dimension |
About L80 × W43 × T4mm |
| weight |
About 10g |
| Recordable point |
Up to 8192 times |
| Power supply |
Lithium battery (CR2032) 1 piece built-in, battery exchange is not possible * |
| Use temperature and humidity |
-30 ~ + 70 ℃, 80% RH or less (however, the range at the time .PC connection of room temperature non-condensing) |
| Storage temperature and humidity |
-40 ~ + 85 ℃, 90% RH or less (without condensation) |
| Measurement interval |
30 seconds / 5 minutes / 10 minutes / 30 minutes / 60 minutes / 90 minutes / 120 minutes |
| Start delay |
0 minutes / 5 minutes / 30 minutes / 45 minutes / 60 minutes / 90 minutes / 120 minutes |
| Alarm range |
-20 ~ -10 ℃ / -10 ~ 0 ℃ / + 2 ~ + 8 ℃ / 0 ~ + 15 ℃ / 0 ~ + 25 ℃ / + 15 ~ + 25 ℃ / others (arbitrarily set the upper / lower limit value) |
| Alarm delay |
0 minutes / 5 minutes / 30 minutes / 45 minutes / 60 minutes / 90 minutes / 120 minutes |
| Alarm type |
Single, cumulative, non-use |
| Dustproof waterproof performance |
IP65 (when sealed in a plastic bag with the included chuck) |
| Supported OS |
Windows 7/8/10 |
| Corresponding USB |
2.0 ** |
| Compliance *** |
- EN12830
- FDA21 CFR Part11
- RTCA DO-160E / F
|
| Proofreading |
Improper |
