| General Specifications |
| Sensor Type |
Type K |
| Measuring Range |
-160°C - 1,372°C |
| Resolution |
199.9°C and below : 0.1°C
200°C and above: 1°C |
| Accuracy |
0 - 199.9°C : ±(0.1% of reading +0.7°C)
-0.1°C or less : ±(0.2% of reading + 1°C)
200°C above : ±(0.2% of reading + 1°C)
(at 25°C ±5°C) |
| Temperature Coefficient |
±(0.015% of reading +0.06°C) / °C |
| Sampling Time |
Approx. 0.5 sec. |
| Linearize Method |
Digital Linearize |
| Functions |
°C, Auto-Power Off, Data Hold, Data Record
(Max/Min/Memory), Relative Measurement |
| Display |
K
----
Auto Off
HOLD
REL
REC
MAX MIN
MEM |
Thermocouple Type
Burn-out
Low Battery
Auto-Power Off
Data Hold
Relative Measurement
Max / Min Data Recording
Max / Min Data Memory
Recorded Memory Data |
Operating
Temp. / Humidity |
0 - 50°C
0 - 90%RH at 0 - 35°C |
| Power Supply |
006P (9V) Battery |
| Battery Life |
Approx. 500 Hours |
| Size / Weight |
Approx. 166(H) x 68(W) x 35(D)mm, Approx. 210g |
| Sensor Connector |
Waterproof Connector |
| Accessories |
Insutruction Manual, 006P battery x 1 pc. |
| Compliance |
CE and RoHS |
| IP Protection |
IP65 (Adjust to No.1, 2 of IEC60529) |
