| Parameters |
ACR, DCV |
| Accuracy |
Resistance accuracy: 0.5%，Voltage accuracy: 0.01% |
| Range |
Test range：0.0001mΩ~3kΩ & 0.00001~200.000V |
| Signal Source |
1kHz, stable frequency: 20ppm |
| Range |
3mΩ~3kΩ with 7 range test.Auto, manual, Nominal. |
| Speed |
All channels open with manual operation: slow 3 times/s, medium:20times/s, fast 40times/s, high-speed 70times/second |
| Result Display |
show, ,ΔABS,Δ%,θ,sorting result |
| Display Max |
R: 33,000 V：400,000 |
| Adjustment |
short-circuit reset full range |
| Comparator |
sorting function.RHI/RNG/RLO output. VHI/VNG/VLO output. NG/OK output. compare way: Absolute value tolerance ±TOL sorting: the absolute deviation between the measured value and the nominal value is compared with the limits of each file. Percent tolerance %TOL sorting: the percentage deviation between the measured value and the nominal value is compared with the limits of each file. Sequential comparison sorting: the measured value is directly compared with the upper and lower limits |
| Trigger |
Internal, Manual, External , Remote |
| Interface |
HANDLER, RS-232C, USB |
| Options |
ATL527A |
| Power |
V:195VAC～245VAC Fre：50Hz Power：15VA |
| Dimensions |
264 x107x350 mm |
| Mass |
4KG |
| Accessories |
ATL527 kelvin test cable,ATL108 RS232 communication cable |
| Other functions |
4.3 inch TFT-LCD color display, full touch operation |
