| Sampling Method & Range |
Diffusion, 0-25% O2 |
| Accuracy |
± 1% of full scale |
| Operating Temperature |
-40 to + 55 C |
| Display |
¾” backlit LCD digital display |
| Sensor Type |
Long-life zirconium oxide sensor cell. |
| Sensor Life |
10+ years under normal conditions |
| Signal Outputs |
4-20 mA analog output (Active)
Dual User Selectable Relays (2amp 30VDC / 240VAC), Audible horn
Please contact PureAire for the available RS-485 option |
| Power Requirements |
24VDC 250mA |
| Dimensions |
6.5 (W) x 4.5 (H) x 3.25 (D) inches; (165.1 x 114.3 x 82.5 mm) |
| Weight |
1.6 lbs.(.8 kg) |
| Enclosure |
Polycarbonate |
| Approvals |
Ce approval & factory calibrated against a NIST traceable reference standard |
| Calibration |
Calibration is not required. Periodic span adjustment as needed. |
| Country of Origin |
USA |
| Harmonized Tariff Code |
8531.10.0045 |
