| Sampling Method |
Diffusion
(Supplied with KF 25 Vacuum Fitting) |
| Gases Detected |
Oxygen (O2) |
| Range |
0 – 25 % O2 & 0-1000ppm Analyzer, please inquire for more details |
| Accuracy |
± 1 % of Reading |
| Operating Temperature |
-40 to +50 ºC |
| Display |
3/4″ LCD Digital Display, Back Lit, 3 Alarms LED´s |
| Sensor Type |
Long-life zirconium oxide sensor cell |
| Sensor Life |
10+ years under Normal Conditions |
| Signal Outputs |
4-20 mA Analog Output (Active)
Dual-Level Alarm Relay Contacts |
| Power Requirements |
24 VDC
250 mA |
| Width |
5.0 in
127 mm |
| Height |
5.5 in
140 mm |
| Depth |
3.25 in
83 mm |
| Weight |
2 lb
0.9 kg |
| Enclosure |
Polycarbonate |
| Calibration |
Calibration is not required. Periodic span adjustment as needed. |
| Country of Origin |
USA |
| Harmonized Tariff Code |
8531.10.0045 |
