- Detection method : Contact method
- Display : 5-digit LCD (10.5-mm character height)
- Measurement update time
+ 1-s automatic update (2-s update for Lo range : 0.5 to 1.0 r/min)
+ 1-s automatic update (2-s update for Hi range : 5 to 10 r/min)
- Rotation speed measurement range : 0.5 to 10,000 r/min (Lo : 0.5 to 2,000.0 r/min, Hi : 5 to 10,000 r/min)
- Circumferential speed measurement range
+ When the KS-200 circumferential ring (provided) is used : 0.05 to 1000.0 m/min
+ When the KS-100 circumferential ring (option) is used : 0.5 to 10,000 mm/s
- Measurement accuracy
+ Low (Lo) range: 0.5 to 1249.9 r/min speeds Within ±0.1 r/min ; 1250.0 to 2000.0 r/min speeds Within ±0.2 r/min
+ High (Hi) range: 5 to 10,000 r/min speeds Within ±1 r/min
- Memory function : 10 data can be memorized.
- Data hold function : Auto power off when 30 seconds have elapsed after the end of measurement.
- Low battery indication : The “LOW” mark is displayed when the battery voltage falls below 3.3 V.
- Over-range display : An “ERROR” mark is displayed.
- Power source : Three AAA-type batteries (1.5 V); Continuous measurement time: Approx. 20 hours (when alkaline batteries are used, at 20ºC)
- Operating temperature : 0 to +40ºC
- Storage temperature : -20 to +55ºC
- Outer dimensions : 63 (W) x 172 (L) x 38.5 (D) mm
- Weight : Approx. 200 g (including batteries)
- Accessories
+ Contact tip for rotation measurement (KS-300) 2 pieces(One tip can be stored in the back side pocket main body)
+ Circumferential ring (KS-200, m/min) 1 piece(can be stored in the back-side pocket of main body)
+ AAA-type batteries 3 pieces
+ User’s manual 1 copy
