| Measuring method |
Two electrode method |
| Measuring range |
Cell constant |
/cm |
0.01 |
Electrical
resistivity |
MΩ·cm |
0.000 to 2.000 |
0.00 to 20.00* |
| kΩ·m |
0.00 to 20.00 |
0.0 to 200.0* |
| |
* With conditions under which temperature compensation is not performed, it is possible to display 0.0 to 100.0 MΩ·cm (0 to 1,000 kΩ·m). |
| Temperature |
˚C |
0 to 100 Resolution: 0.01˚C |
| Repeatability |
Electrical resistivity: ±0.1% full-scale or less, Temperature: ±0.1˚C (for equivalent input) |
| Linearity |
Electrical resistivity: ±0.5% full-scale or less, Temperature: ±0.5˚C (for equivalent input) |
| Transmission output |
Two points 4 to 20 mA DC Input/output insulated type Maximum load resistance 900 Ω |
| Contact output |
Three points Non-voltage contact output Relay contact, SPDT (1c)
Contact function: R1, R2: Selectable from upper limit alarm, lower limit alarm, transmission output hold operation
FAIL: Malfunction alarm
Alarm operation: Output details: Electrical resistivity, temperature |
| Contact input |
One point Contact format: Open collector non-voltage a contact
Contact function: Transmission output hold external input |
| Communication function |
RS-485 Two wire system, Input/output insulated type (not insulated for transmission output) |
| Temperature compensation range |
0 to 100˚C |
| Ambient temperature |
-20 to 55˚C |
| Temperature compensation element |
Pt 1000 (0˚C) |
