| General Specifications |
| Input Power |
120/240 V, 50/60 Hz |
| Battery |
NiMH battery pack
Discharge time – up to 8 hours
Recharge time – 2 hours |
| Data storage |
External SD card (32GB max) |
| Communication |
USB communications
Ethernet communications USB stick for data and configuration file transfer
SD card for direct data transfer |
| Environmental |
Operating: -20° C to 50° C (-4° F to 122° F)
Storage: -30° C to 60° C (-22° F to +140° F)
Relative humidity: 0-95% non-condensing |
| Case |
IP54 enclosure |
| Compliance |
Safety/EMC/Vibration IEC61000-4-30
IEC61000-4-15 IEC61000-4-27
IEC61010-1 IEC61326
IEC60529 MIL-STD-810-G
IEEE1453 CAN/CSA-C22.2 No. 1010.1-92
RoHS2 Directive 2011/65/EU |
| Dsiplay |
Backlit 11.5 cm x 8.5 cm color VGA |
| Power Factor |
Accuracy: ±0.02 + CT error |
| Dimensions |
175 mm x 250 mm x 60 mm (6.89 in. x 9.85 in. x 2.36 in.) |
| Weight Standard unit: |
1.82 kg (4 lbs) |
| Voltage Channels |
4 voltage channels |
