Power frequency AC output
|
|
Voltage range (V)
|
50, 100, 200, 400, 600 (800V is optional), Max. output capacity 20VA
|
|
Current range (A)
|
0.5, 1, 2.5, 5, 10, 20, Max. output capacity 20VA
|
|
Voltage adjustment range
|
0~130%, fineness adjustment 5*10
|
|
Current adjustment range
|
0~130%, fineness adjustment 5*10
|
|
Accuracy of voltage, current, active power and energy
|
0.05%
|
|
Accuracy of reactive power and energy
|
0.1%
|
|
Phase accuracy of current to phase voltage
|
0.05°
|
|
Frequency
|
Adjustment range: 45~65Hz，
Fineness adjustment: 0.001Hz
Setting value accuracy: 0.01Hz
|
|
Phase
|
Adjustment range: 0~359.99°
Fineness adjustment: 0.01°
Setting value accuracy: 0.05°
|
|
Distortion degree of voltage and current output waveform
|
≤0.3%
|
|
Stability of voltage, current and power output
|
≤0.01%/60s (peak-to-peak value)
|
|
Harmonics
|
2~31 times
Amplitude: 0~20%
Phase fineness: 0.01°*N (“N” refers to harmonic order)
|
|
DC output
|
|
Voltage range (V)
|
0.075, 75, 150, 300, 500, 1000, Max. output capacity 20W
|
|
Current range (A)
|
0.5, 1, 2.5, 5, 10, 20, Max. output capacity 20W
|
|
Adjustment range of voltage and current
|
0~120% (not including 1000V), fineness adjustment 5*10
|
|
Stability of voltage and current output
|
≤0.01%/60s (peak-to-peak value)
|
|
Accuracy of voltage setting value
|
0.05%
|
|
Accuracy of current setting value
|
0.1%
|
|
Accuracy at 75mV output (Load ≥5Ω)
|
0.1%
|
|
General parameters
|
|
Power supply
|
Single phase 220V±10%, 50Hz±5%
|
|
Use conditions
|
20℃±10℃, ≤85%RH
|
|
Dimension
|
460*460*175mm
|
|
Weight
|
About 20kg
|
