| Basic Specifications (Accuracy guaranteed for 1 year) |
| [Generation functions] |
| Circuit method |
Bipolar sink and source |
| Constant Voltage |
2.5 V: 0 to ±2.5000 V (±0.03 % of setting ±300 μV, 100 μV resolution)
25 V: 0 to ±25.000 V (±0.03 % of setting ±3 mV, 1 mV resolution) |
| Constant Current |
25 mA: 0 to ±25.000 mA (±0.03 % of setting ±3 μA, 1 μA resolution) |
| Thermoelectric power generation |
K: at TC: 0 °C, -174.0 to 1372.0 °C (±0.05 % of setting ±0.5 °C, 0.1 °C resolution), Other types: E, J, T, R, S, B, N selectable |
| Thermoelectric power generation |
K: at TC: RJ, -174.0 to 1372.0 °C (±0.05 % of setting ±1.0 °C, 0.1 °C resolution), Other types: E, J, T, R, S, B, N selectable |
| Standard resistance (Rs) |
100 Ω (±0.2 Ω) |
| Automatic generation |
Number of memory steps: 20 Interval time: 1 to 99 sec (at CV, CC, TC mode) |
| [Measurement functions] |
| Voltage |
2.5 V: 0 to ±2.8000 V (±0.03 % rdg. ±300 μV, 100 μV resolution, 1 MΩ input resistance)
25 V: 0 to ±28.000 V (±0.03 % rdg. ±3 mV, 1 mV resolution, 1 MΩ input resistance) |
| Current |
25 mA: 0 to ±28.000 mA (±0.03 % rdg. ±3 μA, 1 μA resolution, 25 Ω input resistance) |
| Temperature |
-25.0 to ±80.0 °C (±0.5 °C at 23 ±5 °C, 0.1 °C resolution, use with the RJ sensor 9184) |
| Sampling rate |
Approx. 1.67 times/sec |
