- PH meter, the oxidation-reduction potential (ORP) meter, conductivity meter, total impurity solubility (TDS) meter, dissolved oxygen meter, water quality measuring instrument that was summarized in one the role of salt meter. By connecting the optional sensor to suit the measurement items, data can be recorded on the measurement / SD card.
- The recorded data in CSV format that can be used with commercially available spreadsheet software, you can take advantage of a variety of applications.
- Data can be selected from the automatic recording and manual recording. Sampling set time of automatic recording is possible selected from the 11 steps between 1 to 3600 seconds.
Thông số kỹ thuật
| unit |
Measurement range
|
resolution
|
Measurement accuracy
|
| pH |
0 ~ 14.00pH |
0.01pH |
± (0.02pH + 2dgt) |
- Using sensors: PE-03 (optional)
- It does not include the option of sensor accuracy in the measurement accuracy.
The oxidation-reduction potential (ORP)
| unit |
Measurement range
|
resolution
|
Measurement accuracy
|
| mV |
-1999 ~ + 1999mV |
1mV |
± (0.5% + 2dgt) |
- Using sensors: the ORP water-14 (optional)
- It does not include the option of sensor accuracy in the measurement accuracy.
conductivity
| range |
Measurement range
|
resolution
|
Measurement accuracy
|
| 200μS |
0 ~ 200.0μS / cm |
0.1μS / cm |
± (2% FS + 1dgt) / <100mS / cm |
| 2mS |
0.2 ~ 2.000mS / cm |
0.001mS / cm |
| 20mS |
2 ~ 20.00mS / cm |
0.01mS / cm |
| 200mS |
20 ~ 200.0mS / cm |
0.1mS / cm |
- Using sensors: CDPB-03 (optional)
- FS = full scale (full scale)
- It does not include the option of sensor accuracy in the measurement accuracy.
Total impurity solubility (TDS)
| range |
Measurement range
|
resolution
|
Measurement accuracy
|
| 200ppm |
0 ~ 132ppm |
0.1ppm |
± (2% FS + 1dgt) / <66,000ppm |
| 2,000ppm |
132 ~ 1,320ppm |
1ppm |
| 20,000ppm |
1,320 ~ 13,200ppm |
10ppm |
| 200,000ppm |
13,200 ~ 132,000ppm |
100ppm |
- Using sensors: CDPB-03 (optional)
- It does not include the option of sensor accuracy in the measurement accuracy.
temperature
| unit |
Measurement range
|
resolution
|
Measurement accuracy
|
| ℃ |
0 ~ + 60 ℃ |
0.1 ℃ |
± 0.8 ℃ |
- Using sensors: TP-07(option)
- It does not include the option of sensor accuracy in the measurement accuracy.
Amount of salt
| unit |
Measurement range
|
resolution
|
Measurement accuracy
|
| % |
0 to 12.00% |
0.01% |
± 0.5% FS |
- Using sensors: CDPB-03 (optional)
- FS = full scale (full scale)
- Measured solution temperature range: 0 ~ + 60 ℃
- It does not include the option of sensor accuracy in the measurement accuracy.
Dissolved oxygen (DO)
|
Measurement range
|
resolution
|
Measurement accuracy
|
| 0 ~ 20.0mg / ℓ |
0.1mg / ℓ |
± 0.4mg / ℓ |
- Using sensors: OXPB-11(option)
- It does not include the option of sensor accuracy in the measurement accuracy.
Aerial oxygen
|
Measurement range
|
resolution
|
Measurement accuracy
|
| 0 to 100 percent |
Pasento O 0.1 2 |
0.7 Pasento O ± 2 |
- Using sensors: OXPB-11(option)
- It does not include the option of sensor accuracy in the measurement accuracy.
General specification
| Use temperature and humidity |
0 ~ + 50 ℃, 85% RH or less (without condensation)
|
| Storage temperature and humidity |
-10 ~ + 60 ℃, 85% RH or less (without condensation) |
| Dimensions and weight |
Body: W68 x H177 x D45mm, about 489g (including battery) |
| Power supply |
Alkaline AA batteries × 6 or AC adapter (sold separately) |
| accessories |
instruction manual |
| Proofreading |
Improper |
| option |
- AC adapter: VSM-932EK
- pH electrode: PE-03
- Temperature sensors: TP-07
- ORP sensor: ORP-14
- Conductivity / salinity sensor: CDPB-03
- Dissolved oxygen sensor: OXPB-11
- pH4.00 calibration standard solution: PH-04
- pH7.00 calibration standard solution: PH-07
- 1.413mS calibration standard solution: CD-14
- Probe head with diaphragm: OXHD-04
- For dissolved oxygen sensor electrolyte solution: OXEL-03
[Discontinued] pH electrode / temperature sensor: PE-05T → successor product: PE-03 (pH),TP-07 (temperature)
|
