| Applicable battery |
DC 380V / DC 48V |
| Output voltage |
DC 304-456V / DC 38-60V |
| Output current |
0-30A / 0-100A |
| Working mode |
Can be used stand-alone, multi-machine parallel operation in constant current mode |
| Protection function |
Input terminal over voltage protection, LCD indicate.
Battery voltage polarity reverse protection, buzzer alarm.
Over current protection, LCD indicate.
65°C overheat protection, LCD indicate, buzzer alarm; |
| Single voltage acquisition |
Use 433 RF wireless module, communication distance up to 100 meters, compatible with 2V/4V/6V/12V single battery voltage monitoring, as long as the total voltage does not exceed the threshold, the number of batteries per group is not limited, can be monitored simultaneously 1 ~16 sets of RF wireless monitoring modules, one RF wireless monitoring module can monitor 12 single cells at the same time |
| Control accuracy |
Discharge current ≤±1%; group terminal voltage ≤±0.1%; cell voltage: ≤±0.05% |
| PC communication |
RS485 interface |
| Data storage capacity |
2G bit Flash |
| Working environment |
| Heat transfer |
Forced air cooling |
| Temperature |
Working: 5~50℃, storage: -40~70℃ |
| Humidity |
Relative humidity: 0~90%(40±2℃) |
| Altitude |
Rated altitude 4000m |
| Noise |
<60dB |
| Working power |
| Voltage |
Single phase 3 wire 220V AC (-20%~+30%) , 45~65HZ |
| Withstand voltage test |
Input- shell: 2200Vdc 1min
Input-output: 2200Vdc 1min
Output-shell: 2200Vdc 1min |
| Safety |
Meet EN610950 |
| Wiring |
| AC input |
Public socket for 1~1.5mm2 cable |
| DC output |
Tester 25mm2 cable quick connector (red positive black negative) |
| Dimension & weight |
470*225*460mm, 15kg / 415*180*310mm, 9kg |
