Test voltage
|
10V-500kV
|
|
Power supply
|
Handset: No.5 AA alkaline battery 2 sections (1.5V)
|
|
X and Y detector: No.7 AA alkaline battery 2 sections (1.5V)
|
|
Wireless transmission distance
|
Visual distance 150m
|
|
In-phase
|
Phase angle deviation≤20° (threshold within 0-90°, can be set by user self. )
|
|
Out-phase
|
Phase angle deviation>20° (threshold within 0-90°, can be set by user self. )
|
|
Display accuracy
|
Quantitative measurement≤3°
|
|
Phase angle resolution
|
1°
|
|
Phase sequence measurement
|
Through 120° clockwise/240°anti-clockwise to determine and indicate phase sequence
|
|
Display
|
Positive display LCD, clearly display under the sunshine
|
|
Operation temperature
|
-35℃-+50℃
|
|
Storage temperature
|
-40℃-+55℃
|
|
Relative humidity
|
≤95% RH, Non-condensate
|
|
Handset
|
0.31kg
|
|
X detector
|
0.13kg
|
|
Y detector
|
0.13kg
|
