HPSV 10020/604: High Pressure Safety Shutoff Valve (USA/CDN)Max. Operating pressure: 100 PSI
Nominal diameter: 2" ANSI Flange
HSAV, HSAV/5: Manually operated safety shut-off valveMax. Operating pressure: 500/1500 mbar
Nominal diameter: Rp 3/4 - Rp 2, DN 65 - DN 100
Approvals: EN 161
LGV/5: Vent valveMax. Operating pressure: 500 mbar
Nominal diameter: Rp 3/4, DN 20
Approvals: EN 16304
LV-D/4, LV-D/5: Single-stage air solenoid valveMax. Operating pressure: 200 mbar
Nominal diameter: Rp 1 - Rp 2 1/2, DN 50 - DN 80
LV-D: Single-stage air solenoid valveMax. Operating pressure: 500 mbar
Nominal diameter: Rp 2
MV 10..: Single-stage safety solenoid valveMax. Operating pressure: 1000 mbar
Nominal diameter: Rp 1/2 - Rp 3/4
Approvals: EN 161
MV 502: Ignition gas valveMax. Operating pressure: 500 mbar
Nominal diameter: Rp 1/4, DN 8
Approvals: EN 161
MV/4, MVD, MVD/5, MVDLE/5: Single-stage safety solenoid valveMax. Operating pressure: 200/360/500 mbar
Nominal diameter: Rp 1/2 - Rp 2 1/2, DN 40 - DN 200
Approvals: EN 161
MVD/6 - Safety Shutoff Valve (USA/CDN)Max. Operating pressure: 7 PSI
Nominal diameter: NPT 1/2 - NPT 3
SV...: Safety solenoid valveMax. Operating pressure: 500 mbar
Nominal diameter: Rp 1/2 - Rp 2
Approvals: EN 161
SV/604 - Safety Shutoff Valve (USA/CDN)Max. Operating pressure: 10 PSI
Nominal diameter: NPT 1/2 - NPT 2
SV/614 - Safety Shutoff Valve with Proof of Closure (USA/CDN)Max. Operating pressure: 10 PSI
Nominal diameter: NPT 1/2 - NPT 2
