- Backlit alphanumeric LCD display shows flash rate in flashes per minute.
- Flash Range 30-50,000 FPM (Flashes/Minute) 0.5-830 FPS (Flashes/Sec. or Hz)
- Selectable tracking filter allows for solid phase reading.
- Flash Rate Resolution (Internal Triggering) 0.01 to 1.0 FPM (Menu Selectable)
- Indicators Battery Level, On Target, Time, Auto, Alt, Tach, Lock, and EXT icons
- Flash rates from 30 to 50,000 flashes per minute, adjustable in 1 FPM increments. The all digital, crystal controlled microprocessor keeps readings rock steady.
- Individual in and output TTL jacks for provides signal to remote data collector from accelerometer.
- Average Power - Watts 11Watts @ 3000 FPM; >13Watts @ 3450 FPM
- Tachometer Mode 5-250,000 RPM from external trigger
- Relative Phase Adjustment is user selectable allows reference mark to positioned at a convenient visual location.
- Digital Adjustment Knob 36 detents per revolution and blinking decade selection
- Virtual RPM (Slow Motion) 0-200 VRPM
- Flash Energy (Typical) 230 mJoule up to 3450 FPM
- Flash Duration (Typical) 8-20 microseconds
- External Input (1/8" phone plug) Input Pulse - 0.5 usec min, TTL to 24V max (1/8" phone plug)
- Trigger Output/Remote Sync (Typical) 3.3V TTL Compatible 40 usec pulse-Positive/Negative
- Operating Time 2 hours typical @1800 FPM (operates continuously on AC power)
- Phase Delay - Degrees 0.1 to 359.9 degrees
- Tracking Filter Selectable Wide and Narrow Bandwidths. Filtoer may not lock below 100 FPM
- Time Delay 0.01 to 1000 msec.
- Accuracy ±0.002% of Setting ± least significant digit
