| Input type |
Universal input: thermocouple, RTD, voltage, current, mV |
| Sampling rate |
50 ms |
| Accuracy |
Thermocouple input: either ±1°C ±1 digit or ±0.3% of indicated value ±1 digit, whichever is larger
RTD input: ±0.2% of indication value ±1 digit or ±0.8°C ± 1 digit, whichever is larger
Voltage and current input: ±0.3% FS ± 1digit |
| Control cycle |
0.1 s to 99 s |
| Output type |
Relay contact output, SSR/SSC drive output, current output, voltage output, motor-operated valve control output |
| Control |
ON/OFF, PID, PID2, fuzzy, 2-degrees-of-freedom PID,
auto tuning, self tuning |
| Communication |
Communication port x 1 (for optional USB cable) |
