Bộ điều khiển trọng lượng, Đầu cân TAIPAN 265 STAD
Instrument in DIN box (72x144x170 mm, hole 67x138 mm) for
panel mounting. Backlighted alphanumeric LCD display, 2 lines
x 16 digits (height 5 mm). IP 54 front panel protection rating.
Protection fuse.
ON REQUEST:
- PROFIBUS protocol (it needs additional
module);
- separate modulo for an additional analogue
input and output;
- ETHERNET interface module;
- 24 column printer.
Main features of TAIPAN 265
- Maintaining the flow set point by adjusting IP analog
output, with an alarm output of flow out of tolerance;
- Continuous transmission of the instantaneous flow rate,
detected by analog output proportional to it.
- Ability to set, for batching, the values of presets, sets
and fly with pulse outputs to the achievement of values.
- Possibility of using the unit as SLAVE feeder by setting
the set point as a percentage of full scale through a
serial link to our WTLW instruments.
- Calculation of the weight total and transmission by pulse
output.
- Programming of up to 15 different set points of work,
settable by BCD inputs.
- Able to freeze the analog output value, by means of
logic input, in order to avoid the initial pendulation of
system (which runs all 15 set point).
-Ability to display, during operation, I/O status, the current
weight, current speed, the pulse encoder and the
correction factor set.
- Procedures for the zero setting on working loaded belt
and automatic adjustment factor correction.
- Can be connected with PC / PLC using comunication
protocolsASCII, Modbus-RTU and Profibus (optional
