| Typ: |
B1 |
B2 |
B3 |
| Measuring range |
±3g (ca.±30m/s2) |
±10g (ca.±100m/s2) |
±50g (ca.±500m/s2) |
| Resolution |
<10-3g |
<5·10-3g |
<2·10-2g |
| Frequency range |
0...160Hz |
0...350Hz |
0...550Hz |
| Linearity deviation |
<0,5% |
| Transverse sensitivity |
<1% |
| Mechanical overload resistance in direction of measurement |
10 000 g (approx. 100 000 m/s2) |
| Nominal supply voltage (regulated) |
UbN = 5Volt |
| Permissible range of supply voltage |
Ubz = 3V ... 6V |
| Current drawn at Ub = 5V |
approx.1mA |
| Degree of protection |
IP65 |
| Operating temperature |
-40°C ... +85°C (125°C optional) |
| Storage temperature |
-45°C ... +90°C (125°C optional) |
| Weight (in metal housing without cable) |
approx. 23 grams |
| Standard electrical connection |
3 highly flexible, color-coded wires ø1mm, length approx. 18 cm (special lengths on request) |
| Alternative electrical connection |
0.5m strong, flexible, shielded cable ø2.1mm (special lengths on request)
3 flexible, color-coded wires with Teflon insulation for extended temperature range |
| Values for analog DC output at UbN = 5 Volt |
| Sensitivity |
approx. 140mV/g |
approx. 30mV/g |
approx. 7,5mV/g |
| Temperature drift of sensitivity |
<+6·10-2 % / K |
| Temperature drift of zero point |
<0.1mV/K |
| Zero offset at Ub=5V |
2.5±0.1Volt - generally: 0.5Ub±4% |
| Output impedance |
10 kOhm |
