| Item |
Specifications |
| Mounting method |
Clamp-on type |
| Measurement fluid |
Saturated steam |
| Measuring method |
Transit time difference |
| Flow velocity |
0 to ±50 m/s |
| Accuracy |
For required straight pipe length (upstream: 20 D or longer; downstream: 10 D or longer)
Flow velocity 0 to 10 m/s:
±0.3 m/s (50 A),
±0.4 m/s (65, 80, 100 A)
Flow velocity adove 10 to 30m/s:
±3% of rate (50 A),
±4% of rate (65, 80, 100 A)
Flow velocity above 30 to 50 m/s: ±5% of rate |
| Required straight pipe length |
Upstream: 20 D or longer; downstream: 10 D or longer |
| Piping material |
Carbon steel, stainless steel |
| Pipe diameter |
50 mm, 65 mm, 80mm, 100 mm |
