Máy hiện sóng số Digital Oscilloscope GW Instek GDS-2072E
Instek GDS-2072E 70 MHz, 2-Channel 1 GS/s, 10 Mpts. with USB/LAN, VPO Digital Storage Oscilloscope
- 70MHz, 2-Channel, Digital Storage Oscilloscope
- 200/100/70MHz Bandwidth Selection; 2 or 4 Channels
- 1GSa/s Real-Time Sampling Rate for Each Channel (2ch model) ;
- 1GSa/s Maximum Real-Time Sampling Rate (4ch model)
- Standard 10M Maximum Memory Depth and VPO Waveform Display Technology
- Waveform Update Rate of 120,000 wfm/s
- 8 ” WVGA TFT LCD Display
- FFT with Maximum 1M points to Provide Higher Frequency Domain Resolution Measurement
- High and Low Pass Digital Filter Functions
- 29,000 Sections of Segmented Memory and Waveform Search Functions
- I2C/SPI/UART/CAN/LIN Serial Bus Trigger and Decoding Function
- Data Log Function Tracks Signal Changes Up To 100 hours
- Provide Remote Internet Storage Function
