| Output-Voltage Range |
0.100kV~ 5.000kV |
| Output-Voltage Resolution |
2V/step |
| Output-Voltage Accuracy |
± (1% of setting + 5V) with no load |
| Capacity |
500 VA (5kV/100mA) |
| Maximum Rated Current |
100mA (0.5kV |
| Output-Voltage Waveform |
Sine wave |
| Output-Voltage Frequency |
50 Hz / 60 Hz selectable |
| Voltage Regulation |
± (1% reading + 5V) [Maximum rated load ->no load] |
| Voltmeter Accuracy |
± (1% of reading + 5V) |
| Current Measurement Range [1] |
0.001mA~100.0mA |
| Current Best Resolution |
0.001mA(0.001mA~1.100mA)
0.01mA(01.11mA~11.00mA)
0.1mA(011.1~100.0mA) |
| Current Measurement Accuracy |
± (1.5% of rdg + 30 counts) when HI SET<1.11mA
± (1.5% of rdg + 3 counts) when HI SET=1.11mA |
| Window Comparator Method |
Yes |
| Sweep Function [2] |
Yes |
| RAMP (Ramp-Up Time) |
0.1s~999.9s |
| TIMER (Test Time) [3] |
OFF, 0.5s~999.9s |
| Output-Voltage Range |
0.100kV~ 6.000kV |
| Output-Voltage Resolution |
2V/step |
| Output-Voltage Accuracy |
± (1% of setting + 5V) with no load |
| Maximum Rated Load |
100W (5kV/20mA) |
| Maximum Rated Current |
20mA (0.5kV |
| Voltage Regulation |
± (1% reading + 5V) [Maximum rated load ->no load] |
| Voltmeter Accuracy |
( (1% of reading + 5V) |
| Voltage Regulation |
± (1% reading + 5V) [Maximum rated load ->no load] |
| Voltmeter Accuracy |
± (1% of reading + 5V) |
