| Frequency |
Range |
9 kHz to 3 GHz |
| Resolution |
1 Hz |
| Frequency Reference |
Accuracy |
±(period since last adjustment X aging rate) + stability over temperature + supply voltage stability |
| Aging Rate |
±1 ppm max. |
1 year after last adjustment |
| Frequency Stability over Temperature |
±0.025 ppm |
0 to 50 °C |
| Supply Voltage Stability |
±0.02 ppm |
|
| Frequency Readout Accuracy |
Start, Stop, Center, Marker |
±(marker frequency indication X frequency reference accuracy + 10% x RBW + frequency resolution) |
| Trace points |
Max 601 points, min 6 points |
| Marker Frequency Counter |
Resolution |
1 Hz, 10 Hz, 100 Hz, 1 kHz |
| Accuracy |
±(marker frequency indication X frequency reference accuracy + counter resolution) |
RBW/Span >=0.02 ; Mkr level to DNL>30 dB |
| Frequency Span |
Range |
0 Hz (zero span), 100 Hz to 3 GHz |
|
| Resolution |
1 Hz |
|
| Accuracy |
± frequency resolution1 |
RBW: Auto; |
| Phase Noise |
Offset from Carrier |
|
Fc =1 GHz; RBW = 1 kHz, VBW = 10 Hz; Average ≥ 40 |
| 10 kHz |
<-88 dBc/Hz |
Typical |
| 100 kHz |
<-95 dBc/Hz |
Typical |
| 1 MHz |
<-113 dBc/Hz |
Typical |
| Resolution Bandwidth (RBW) Filter |
Filter Bandwidth |
1 Hz to 1 MHz in 1-3-10 sequence |
-3dB bandwidth |
| 200 Hz, 9 kHz, 120 kHz, 1MHz |
-6dB bandwidth |
| Accuracy |
± 8%, RBW = 1MHz |
Nominal |
| ± 5%, RBW < 1MHz |
Nominal |
| Shape Factor |
< 4.5:1 |
Normal Bandwidth ratio: -60dB:-3dB |
| Video Bandwidth (VBW) Filter |
Filter Bandwidth |
1 Hz to 1 MHz in 1-3-10 sequence |
-3dB bandwidth |
