DC to DC Isolated Signal Conditioners
Factory Configured
API 4300 G from $299
Open Datasheet
Download Datasheet
|
API 4300 G
Specify input range
Factory configured
0-100 mVDC to 0-500 VDC
±100 mVDC to ±10 VDC
0-100 μADC to 0-900 mADC
Specify output range
Factory configured
0-1 V to 0-10 V
±1 V to ±10 V
0-1 mA to 0-20 mA, 4-20 mA
|
- Hot-swappable plug-in design
- Replaces Action AP 4300
- I/O LoopTracker LEDs
- Output test button
- Full I/O/power isolation
- 18 V loop power supply
- Uses API-008 8-pin socket
- 115 VAC powered
- A230 option for 230 VAC
- P option for 85-265 VAC, 60-300 VDC power
- D option for 9-30 VDC
|

API 4300 G
|
Low Range DC to DC Isolated Signal Conditioners
Factory Configured
API 4310 G from $329
Open Datasheet
Download Datasheet
|
API 4310 G Narrow/Low Input
Specify input range
Factory configured
0-10 mV to 0-100 mV
±10 mV to ±100 mV
0-100 μA to 0-1 mA
Specify output range
Factory configured
0-1 V to 0-10 V
±1 V to ±10 V
0-1 mA to 0-20 mA, 4-20 mA
I/O reversal available
|
- Hot-swappable plug-in design
- Replaces Action AP 4310
- I/O LoopTracker LEDs
- Output test button
- Full I/O/power isolation
- 18 V loop power supply
- Uses API-008 8-pin socket
- 115 VAC powered
- A230 option for 230 VAC
- P option for 85-265 VAC, 60-300 VDC power
- D option for 9-30 VDC
|
API 4310 G
|
DC to DC Isolated Signal Conditioner
Factory Configured
APD 4300 from $309
Open Datasheet
Download Datasheet
|
APD 4300
Specify input range
0-100 mVDC to 0-300 VDC
±100 mVDC to ±10 VDC
0-1 mADC to 0-1000 mADC, 4-20 mA
Specify output range
Factory configured
0-1 V to 0-20 V
±1 V to ±10 V
0-1 mA to 0-20 mA, 4-20 mA
I/O reversal available
APD 4300 PLC
Input range: 4-20 mA
Output range: 4-20 mA
|
- Removable plugs
- I/O LoopTracker LEDs
- Output test button
- Output test terminals for manual override capability
- Full I/O/power isolation
- Selectable I/O sink/source
- 15 V input loop power supply
- 20 V output loop power supply
- Universal power 85-265 VAC, 60-300 VDC
- D option for 9-30 VDC, 10-32 VAC power
- Correct sink-sink or source-source mismatches
- Isolate single-ended inputs
- Eliminate PLC/DCS ground loops
- Use with Allen Bradley, GE/Fanuc, IDEC,
Omron, Mitsubishi, Modicon, Siemens,
Panasonic, Honeywell analog inputs
|

APD 4300
|
DC to DC Isolated Signal Conditioner
Field Selectable Minuteman Setup
API 4380 G from $299
Open Datasheet
Download Datasheet
|
24 Field configurable inputs
0-50 mV to 0-10 V
±5 V, ±10 V
0-1 mA to 0-20 mA, 4-20 mA
16 Field configurable outputs
0-1 V to 0-10 VDC
±5 V to ±10 V
0-2 mA to 0-20 mA, 4-20 mA
|
- Minuteman one-minute setup
- Hot-swappable plug-in design
- Replaces Action AP4380, Wilkerson MM4380
- I/O LoopTracker LEDs
- Output test button
- Full I/O/power isolation
- 18 V loop power supply
- Uses API-008 8-pin socket
- 115 VAC powered
- A230 option for 230 VAC
- P option for 85-265 VAC, 60-300 VDC power
- D option for 9-30 VDC power
|
