- MEASURING RANGE 0.05 TO 80 M – TYPICAL ACCURACY ± 1.0 MM
- POWER RANGE TECHNOLOGY™
- ILLUMINATED 3-LINE DISPLAY
- MARKING-OUT FUNCTION
- MULTIFUNCTIONAL END PIECE
- PYTHAGORAS FUNCTION (INDIRECT MEASUREMENT FUNCTION AS PER PYTHAGORAS’ THEOREM)
- PAINTER FUNCTION
- IP54
- Min. measuring range : 0.05 m
- Max. typical range : 80 m
- Range with unfavourable conditions : 50 m (164 ft)
- Resolution : 0.1 mm (1/32 in)
- Typical measuring tolerance : ± 1.0 mm
- Maximum measuring tolerance : ± 2.0 mm (0.08 in)
- Ø of the laser point at distance 10 m [mm] : 6
- Ø of the laser point at distance 50 m [mm] : 30
- Ø of the laser point at distance 100 m [mm] : 60
- class : 2
