| General |
| Display |
240 x 64 Ice Blue Dot Matrix LCD |
| Memory |
100 sets for panel setting save and recall |
| Power Source |
AC 100 V / 120 V / 220 V / 230 V ±10% |
| Line Frequency |
50/60Hz |
| Comsumption |
700VA (max) |
| Dimensions |
330(W) x 148(H) x 460(D) mm |
| Weight |
Approx. 17kg (max) |
| AC Ground Bond |
| GROUND BOND |
| Output-Current |
03.00A~ 40.00A ac |
| Output-Current Resolution |
0.01A |
| Output-Current Accuracy |
3A≦I≦8A : ± (1% of setting + 0.2A)
8A< I≦40A : ± (1% of setting + 0.05A) |
| Test-Voltage |
8Vac max (open circuit) |
| Test-Voltage Frequency |
50Hz/60Hz selectable |
| Resistance Measurement Range |
1.0mΩ ~ 650.0mΩ |
| Resistance Measurement Resolution |
0.1mΩ |
| Resistance Measurement Accuracy |
± (1% of reading + 2mΩ) |
| Window Comparator Method |
Yes |
| TIMER (Test Time) |
0.5s~999.9s |
| GND |
OFF (fix) |
| Test Method |
Four Terminal |
| MEMORY |
