- automatic range switching dual scale scale plate adopted with you Yes to display in two stages the resistance of the low range and high range so as to obtain a resolution of times in a single meter. Moreover, the range switching is done automatically, it is easy display in matching LED to the color of the range.
- drip-proof structure adopted by using the packing to each section takes a little raindrops As is okay, we have to protect the circuit inside.
- plastic hard case standard equipment is hard with a case that was designed specifically for this model. Also measured cords can be stored compactly together. In addition, because the plastic case, durability is preeminent.
- We are also available recorder adapter code as an option.
Thông số kỹ thuật
| Use power |
SUM-3 (1.5V) × 8 |
| Rated voltage |
DC5000 / 10000V |
| Measurement range |
DC5000V
0 ～ 5000Emuomega (5Jiomega)
200000Emuomega (200Jiomega) |
DC10000V
0 ～ 10000Emuomega (10Jiomega)
400000Emuomega (400Jiomega) |
| Dielectric strength |
AC5000V / 1 minutes in an electric circuit and outer box |
| Body dimensions |
200 (D) × 140 (W) × 80 (H) |
| Case dimensions |
270 (D) × 260 (W) × 100 (H) |
| Body weight |
About 1kg (battery, line probe included) |
| accessories |
Hard case, batteries and ground cords guard code hook bracket |
