■ Six-in-one comprehensive analysis:
High-power AC withstand voltage analysis
DC voltage analysis
Insulation resistance analysis
Turn-to-turn insulation analysis
DC low resistance analysis
Inductance test analysis (option)
■ High-resolution: 7-inch 800 × 480 dots, TFT-LCD display
■ Eight-channel switching technology that can test eight
different components simultaneously
■ 200VA power AC withstand voltage design, in line with UL
1004-1 motor test standards
■ Insulation resistance test: maximum voltage can reach 5kV
■ DC / IR automatic rapid discharge function
■ Turn-to-turn insulation test: sampling ADC promoting to
12bit, 200MHz sampling rate
■ DC low resistance test: support DC resistance calculation of
△ Y-type motor
■ DC low resistance temperature conversion function and
optional temperature sensor
■ Quick contact check function to realize rapid detection of
test fixture
■ New-type high voltage test fixture
■ Inductance test analysis of up to 100kHz frequency
Four-terminal Kelvin test of DC low resistance and
inductance
■ Test steps up to 32
■ Internal file storage and external U disk file saving
......
