■ 8-channel parallel output of withstand voltage,
and each channel is non-interfering
■ Output: AC: 5kV/10mA; DC: 6kV/5mA
■ Insulation resistance test voltage: 0.10kV -1.00kV
■ Each channel can be extended with four-channel scanners,
support 4 four-channel scanners at most which means one
instrument can be extended to 128 channels
■ Four-channel scanner supports contact check function
■ 7-inch 800×480 dot-matrix, TFT-LCD display
■ Chinese and English operation interface and concise
interface operation design
■ Enhanced security: electric shock protection
■ Rapid discharge and arc detection function
■ Arbitrarily set voltage rising time and test time in 999.9
seconds; freely set waiting time for insulation resistance
■ Key-Lock Function
■ Display the PASS/FAIL result of each channel independently
and the total result simultaneously
■ Store 100 test files and each file can hold at most 20 testing
steps
......
