Thiết bị kiểm tra relay RT-30K Soukou

Mã sản phẩm: RT-30K |
Thương hiệu: Soukou
Giá gốc:

Giá khuyến mại: Liên hệ ( Đã có VAT )

Tiết kiệm: (0%)
Thiết bị kiểm tra relay
Model: RT-30K
Hãng: SouKou
Thông tin sản phẩm
- Lightweight and compact
- voltage relay test when the 0 variable can be up to ~ 300V (the case of the RT-30K). RT-20K2 in up to 750V can be test of variable possible DGR (simple direction)
- to the power supply resistance portion, radiating fan a standard feature
- voltmeter, the ammeter, the true effective value in terms of indication the moving coil type adopted (it is easy to very hard to read in a linear scale.)
- the auxiliary power, adopt a convenient breaker (10A) (exchange-DC output)
- MAKE-BREAK is automatic determination. In addition, the output voltage from the TRIP.T is, there is no shock of worry as low as DC12V. (MAKE · BREAK mode)

Thông số kỹ thuật

voltmeter ~ 75 AC0 / 150/300 / 750V RT-20KⅡ
AC0 ~ 75/150 / 300V RT-30K
0.5 grade moving coil type with mirror
(true effective value in terms of instruction)
ammeter AC0 ~ 0.25 / 0.5 / 1 / 2.5 / 5/10/25 / 50A 0.5 grade moving coil type with mirror (true effective value in terms of instruction)
counter 0 ~ 199.999sec resolution 1Ms
200.000 ~ 1999.99Sec resolution 10ms (with automatic carry function)
Counter accuracy 0.01 Pasento rdg ± ± ± 1Dgt 5Ms ± ⊿T
⊿T: each error of the stop signal
contacts, DC voltage 1Ms ±
AC voltage (5 ~ 10V) ± 5Ms
AC voltage (10 ~ 20V) ± 2.5Ms
AC voltage (more than 20V) ± 1ms
self-power ± 3ms
case of ※ stop due to self-supply, depends on the supply load state of the power supply (back electromotive force due to the rotation device, etc., the residual voltage of the capacitor, etc.). The above accuracy, power supply of the counter is the accuracy of to completely cut off.
External dimensions 345 (D) × 470 (W) × 185 (H)
weight RT-20KⅡ 10.9kg / RT-30K 10kg
accessories Test code set (with storage bag) owner manual case cover
