| Input voltage |
AC0 ~ 130V 50 / 60Hz |
| Output voltage |
AC0 ~ 13kV (one side ground) |
| capacity |
3.25kVA (30 minute rating) |
| Winding ratio |
1: 100 |
| Charging ammeter |
AC0 ~ 50/200 / 500mA / 2A
moving coil-shaped, with a 1.0 grade mirror |
| Measuring element |
Transformer output current, charging current, reactor current |
| Circuit breaker setting range |
250mA (optional setting) |
| External dimensions |
200 (D) × 230 (W) × 406 (H) with casters |
| weight |
About 25kg |
| accessories |
Test for the code set-case cover |
