- can test the following items by combining the OCR tester
- voltage relay test (OVR, UVR)
- direction of land絡継electronics test (simple direction)
- output voltage meter and secondary current meter in the case of performing an alternating pressure test It will be.
Thông số kỹ thuật
| Use power |
Supplied from the OCR tester |
| Output voltage |
AC15 / 150/300/500 / 1000V |
| voltmeter |
AC15 / 150/300/500 / 1000V
(VR, DGR, the voltage output and the simultaneous switching)
moving coil-shaped, with a 0.5 grade mirror (True RMS conversion method) |
| ammeter |
AC50 / 150 / 500mA / 1.5A / SHORT
moving coil-shaped, with a 0.5 grade mirror (True RMS conversion method) |
| External dimensions |
300 (D) × 500 (W) (excluding protrusions) × 200 (H) |
| weight |
11kg |
| accessories |
Test code set owner manual case cover |
