| Use power |
AC100V ± 10% 50 / 60Hz |
| Output voltage |
DC1 ~ 114V |
| Output current |
4.5A up to 24V, up to 110V 3A |
| Power fluctuation |
0.1V or less (in the input power supply range) |
| Load fluctuation |
0.1V or less |
| Output voltage meter error |
0 ~ 150V (resolution 0.1V)
± 1.0 Pasento rdg ± 3Dgt
3 digit 1/2 7-segment LCD |
| Overcurrent protection |
Output is stopped at 110% of the output capacity |
| Overheat protection |
If the device internal becomes abnormal temperature, output stop |
| External dimensions |
190 (D) × 350 (W) × 290 (H) |
| weight |
About 7.5kg |
| accessories |
Lead-manual |
