■ Voltage: 100V-5kV, 10V steps, 8 channels
■ Low inductance impulse test: down to 10μH
■ Maximum measuring speed: 6meas/sec
■ Up to 200Msps waveform sampling rate
■ First winding tester compatible with LXI standard
■ Each channel can be programmed and controlled as high
terminal, low-terminal and OFF
■ 20 test procedures can be added at most
■ 65k color 7”TFT wide display screen
■ Storage depth of 6k Bytes
■ High bandwidth analog acquisition circuit
■ High-fidelity corona extraction algorithm (patent technology)
■ Four waveform comparison methods
■ Automatic storage of instrument parameters
■ Measurements on voltage, time and frequency
■ Amplification, stretch and movement of the waveform for
accurate display
■ Multi-sample average, average processing of 32 standard
waveforms
■ Destructive testing for your correct choose of voltage
■ Use demagnetized impulse to ensure the conformity of
tested waveforms
■ Login of different user right for easy management
■ 20 groups of instrument files can be stored and
automatically loaded
■ Screen information can be stored in USB disk (COPY key)
■ System firmware can be automatically upgraded through
USB-disk
■ Selectable Chinese and English operation interfaces
■ Four selectable display interface effects
■ Foot control interface for easy measurements
■ Handler interface to realize on-line operation
■ RS232C, USB Device and LAN interface to realize remote
control
......
